Following up the most advanced charging technology and Specialized in chargers more than 20 years.
Specifications:
Input 100-240V~,50/60Hz; 2.5A Max
Single port mode
USB-C1 Output 5V⎓3A, 9V⎓3A, 12V⎓3A, 15V⎓3A,20⎓5A, 28⎓5A (Max 140W)
PPS:3.3V-11V 5A,3.3-21V,4A
USB-C2 Output 5V⎓3A, 9V⎓3A, 12V⎓3A, 15V⎓3A,20⎓5A, (Max 100W)
PPS:3.3V-11V 5A,3.3-21V,4A
USB-C3 Output 5V/3A 9V/3A 12V/2.5A 15V/2A 20V/1.5A (Max 30W)
PPS:3.3-11V 3A
USB-A Output 5V⎓3A, 9V⎓2A, 12V⎓1.5A (Max 18W)
Two-port mode
USB-C1+USB-C2:65W+65W (5V/3A 9V/3A 12V/3A 15V/3A 20V/3.25A;PPS:3.3-11V 5A)
USB-C1+USB-C3: 100W+30W
USB-C1+USB-A: 100W+18W
USB-C2+USB-C3: 100W+30W
USB-C2+USB-A: 100W+18W
USB-C3+USB-A: 7.5W+7.5W (share 5V/3A)
Three-port mode:
USB-C1+USB-C2+USB-C3: 65W+45W(5V/3A 9V/3A 12V/2.5A 15V/2A 20V/2.25A;PPS:3.3-11V 4A)+ 30W
USB-C1+USB-C2+USB-A: 65W+45W+18W
USB-C1+USB-C3+USB-A: 100W+7.5W+7.5W (share 5V/3A)
USB-C2+USB-C3+USB-A: 100W+7.5W+7.5W
Four-port mode:
USB-C1+USB-C2+USB-C3+USB-A: 65W+45W+7.5W+7.5W
Dimension Size( without of plug):65.6x92x32.5mm
Weight: 320g
